CI 490-490 Iridium Satcom Round Antenna | 1616–1626.5 MHz, 50 Ω, 3 dB Gain, TNC Female Connector

Product Description

The CI 490-490 antenna (EDMO# CI-490-490) is a four-through-hole-mount style round Iridium antenna with TNC ports. This antenna is Iridium C159a certified and designed for airborne Iridium based telephone, email, asset tracking or safety services. It is suitable for top mounting on both light and heavy fixed-wing single-engine and multi-engine aircraft and business jets.

Specifications

• Weight:
  6.2 oz
• Frequency:
  1616–1626.5 MHz
• VSWR:
  1.5:1
• Polarization:
  RHCP
• Radiation Pattern:
  Hemispherical
• Impedance RF:
  50 Ω
• Power Handling TX:
  6.5 W
• Lightning Protection:
  DC Grounded
• Gain:
  +3 dBic @ Zenith
• Speed:
  330 KIAS @ Sea Level
• Finish:
  White Polyurethane Enamel
• Connector:
  TNC Female
• FAA TSO:
  C159a
• RTCA Environmental:
  DO-160G

Product Codes

• Mfr Part No
  CI 490-490
• ECCN
  7A994
• PROAPP
  PT2316NM
• SCHEDULE B CODE
  8529.10.4000
• TSO
  C159a

Documentation

• CI 490-490 Data Sheet
• CI 490-490 Product Drawing
