AA34-300 Radio Interface | TSO C50c

CANYON AEROCONNECT

Call For Pricing

In stock

EDMO # AA34-300

MFR Part # AA34-300

Need help placing an order? Call 800-235-3300 or Contact us

Product Description

The AA34 universal radio interface integrates with an aircraft radio to handle the interfacing and switching requirements of mobile or CB radio systems. This unit provides microphone excitation; relay keying, and sidetone generation which also is fully isolated from the aircraft ground.

Features

No product features currently available.

Also Purchased

Specifications

Weight:

0.40 lb (180 g)
Dimensions:

1.3 x 2.71 x 4.54 in (33 x 68.8 x 115.3 mm)
Mounting:

bulkhead mound with four 10-32 screws
Materials and Finish:

5052-H32 brushed aluminum chassis and cover with conversion finish
Connectors:

25 pin male filtered D-sub
Input Power:

13.8 VDC±10% mVRMS or 27.5 VDC±10% (select by pin), at 70 mA
Input Signals:

mic, 250 mVRMS @ 150Ω ±10% audio, 2.5 VRMS @ 600Ω ±10%
Output Signals:

mic, adjustable to 1.5 VRMS max into 600Ω or 178 mVRMS into 8Ω audio, 100 mW into 8Ω or 600Ω nominal
Frequency Response:

<3 dB from 350 Hz to 6 Hz
Distortion:

<10% @ rated output
Noise Level:

>50 dB down from rated output (without signal)
Temperature:

-20°C to 55°C, operating -55°C to 85°C, survival
Altitude:

35,000 ft
Humidity:

95% non-condensing
Shock:

6 G (any axis)
Vibration:

RTCA/DO-160C categories (B, M, N)
Approval:

TSO-C50c (RTCA/DO-170 /Class II, RTCA/DO-160C)
