Tinnerman Clip | 6-32

Tinnerman Clip | 6-32

EDMO DISTRIBUTORS, INC

Call For Pricing
In stock
EDMO # S10233-3B
MFR Part # C8095-632-3B
Need help placing an order? Call 800-235-3300 or Contact us

Product Description

Tinnerman U-type nuts snap into position over a panels edge and are ideal in blind or hard to reach locations without requiring welding or riveting.

This Tinnerman U-nut (S10233-3B) uses a 6-32 screw and fits panels with a thickness of 0.045 to 0.062 inches and has a panel hole diameter of 0.187 inches.

Features

  • U-nut type
  • Ideal for instrument panels
  • Spring steel

Also Purchased

Specifications

  • Screw size:
    6-32
  • Panel thickness:
    0.045 to 0.062 inch
  • Dimensions:
    0.82 to 0.312 inch
  • Maximum center of hole to edge:
    0.468 inch
  • Panel hole diameter:
    0.187 inch

Related Products

Product Codes

  • Mfr Part No
    C8095-632-3B
  • ECCN
    EAR99
  • SAE
    1050-1065
  • SCHEDULE B CODE
    7318.16.0000
