AV-535 FM Bent Whip Antenna | 138–174 MHz

AV-535 FM Bent Whip Antenna | 138–174 MHz

RAMI

Call For Pricing
In stock
EDMO # AV-535
MFR Part # AV-535
Need help placing an order? Call 800-235-3300 or Contact us

Product Description

The AV-535 is an FM extended band bent whip antenna suitable for belly mounting. It is designed to operate in the public service and business bands for airborne communication. The antenna is rated at speeds up to 350 mph and altitudes up to 50,000 feet. It is a direct replacement for the CI 292-3.

Features

  • Direct replacement for the CI 292-3
  • FM Extended band application
  • 138–174 MHz frequency range
  • Vertical polarization
  • Omni-directional pattern
  • Backed by the RAMI Limited Lifetime Warranty

Also Purchased

Specifications

  • Application
    : FM Extended band
  • Frequency
    : 138–174 MHz
  • Impedance
    : 50 Ohms Nominal
  • VSWR
    : 3.0:1 Maximum
  • Polarization
    : Vertical
  • Pattern
    : Omni-directional
  • Connector
    : BNC Female
  • RF Power Capacity:
    100 Watts
  • Color
    : Gloss White

Related Products

Product Codes

  • Mfr Part No
    AV-535
  • ECCN
    7A994
  • SCHEDULE B CODE
    8529.10.4000
