AV-529 VHF Communications Whip Antenna | 118–137 MHz

Product Description

The AV-529 is designed for broadband communications (118-137 MHz). It has a die-cast aluminum base and a uniquely designed radiator encapsulated in a fiberglass whip. The antenna is supplied with a weather-sealing gasket and mounting hardware. The AV-529 antenna is designed to operate at speeds up to 350 mph and altitudes of 50,000 ft. It has a drag force of 3.43 lb @ 250 mph. This antenna is a direct replacement for the CI-291.

Specifications

• Weight
  : 8 oz
• Height:
  22 in, maximum
• Frequency:
  118–137 MHz
• Impedance:
  50Ω, nominal
• VSWR:
  1.8:1, maximum
• Polarization:
  Vertical
• Pattern:
  Omni-directional
• Connector:
  BNC (Female)
• RF Power Capacity:
  25 Watts
• FAA Approvals:
  TSO-C37d, TSO-C38d

Product Codes

• Mfr Part No
  AV-529
• ECCN
  7A994
• PROAPP
  PT2530CE
• SCHEDULE B CODE
  8529.10.4000
• TSO
  C37d,C38d

Documentation

• RAMI Limited Lifetime Warranty
