CH93 CHRONOS Digital Clock High Power USB Charger | Dual USB-A ports

MD93H Digital Clock | Dual 3.0 Amp USB Charger

Select an option

MID-CONTINENT INSTRUMENTS AND AVIONICS

Call For Pricing

In stock

EDMO # 6420093-2

MFR Part # 6420093-2

Need help placing an order? Call 800-235-3300 or Contact us

Product Description

The CH93 series CHRONOS Digital Clocks are a multifunction clock which displays volts, temperature, time, countdown time, and stopwatch, and also comes available with multiple USB charging options. The CH93 installs in to a 2-1/4 inch avionics panel cutout and power is drawn from the aircraft main bus to power the unit. The white, seven-segment LED clock can displays several modes: local time, universal time, flight timers, elapsed and countdown timers and optionally, bus voltage and up to two temperature inputs. The daylight readable display features two methods of brightness controls: automatically using the internal photocell or manually with external dimming bus voltage. An internal battery maintains clock time and flight timer memory when the aircraft is not in use.

This CH93 digital clock (EDMO# 6420093-2) features Dual USB-A charging ports, local time, UTC/Zulu time, flight timer, countdown timer, stopwatch.

Features

Six-digit, seven-segment LED clock
Time modes: local time, UTC/Zulu time, flight timer, countdown timer, and stopwatch
Clock settings include 12- or 24-hour mode and seconds On or Off
External lighting control and built-in photocell for automatic dimming
Internal, field-replaceable battery maintains time and Flight Timer memory, without aircraft power
Compact, 2-inch size fits standard panel cutout
30 watts / 6 amps USB power
Compatible with Apple, Android and other USB devices
Protects itself and the charging device from short circuit, power surges and over-current potential
The USB charging ports are designed as dedicated charging ports to industry-standard protocol per USB Battery Charging 1.2 Compliance plan. Some models also comply with the higher power requirements of USB Power Delivery 2.0 and 3.0

Also Purchased

Specifications

Weight:

5.0 oz
Dimensions:

2.39 x 2.39 x 1.15 in
Power Input:

10 – 32 VDC, 36 watts maximum 2.6A @14 VDC; 1.3A @ 28 VDC
USB Power Output:

5 – 0.25 VDC, 30 watts, 6 amp
Clock Accuracy:

±0.5 sec in 24 hours, ±3 min per year
Display Modes:

Local time, UTC/Zulu time, flight timer, countdown timer, stopwatch
Altitude:

55,000 ft
Temperature:

-40°C to 70°C (operating)
USB Interface:

Single USB-A port
Mounting:

Rear-panel mounted, (4) #6 screws
Connector Kit:

MCIA P/N 8017287
Case:

Anodized aluminum black
Certification:

FAA TSO certified to C71 EASA ETSO certified to C71 RTCA DO-160G qualified
