Series 2 CPC Connector Receptacle | Size 11 Shell, 8-Position, Free-Hanging, Thermoplastic

Product Description

Series 2 CPC connectors are constructed with thermoplastic material providing a flammability rating of UL 94 V-0.

This circular connector receptacle (EDMO# 205841-2) features a size 11 shell size, 8 contact positions, and a free-hanging mounting receptacle. Thermoplastic construction.

Specifications

• Height:
  28.57 mm Diameter: 17.47 mm Connector Type: standard circular connector series 2 Housing Material: thermoplastic Mating Style: threaded Mounting Angle: straight Mounting Style: free hanging Number of Positions: 8 position Shell Size: 11 Shell Style: receptacle Thread Size: 5/8-24 Flammability Rating: UL 94 V-0

Product Codes

• Mfr Part No
  205841-2
• CSA
  LR7189
• ECCN
  EAR99
• SCHEDULE B CODE
  8536.90.4000
• UL
  E28476
