Product Description

tailBeaconX is the next era of global ADS-B. Compatible with surface and space-based ADS-B surveillance systems, tailBeaconX is a Mode S Extended Squitter ADS-B transponder and aviation GPS integrated into an LED rear position light. With global compliance, tailBeaconX is the key to limitless destinations.

The AV-30 is a highly capable, fully digital, multi-mode instrument that mounts in the legacy 3⅛ inch round instrument panel cutout. It can be field configured as either an Attitude Indicator (AI) or a Direction Indicator (DG), contains an internal battery, and allows for a wide variety of pilot customization.

Version (EDMO# UAX9010801) includes the tailBeaconX Experimental (UAX9005801) and the AV-30E Experimental Multi-function Panel Display.

Features

tailBeaconX Features:
Mode S ADS-B OUT transponder
1090MHz
Integrated GPS receiver
Aireon compatible
LED lighting
Rear position light
Space-based and ground-based antennas
Minimal installation
AV-30E Features:
AoA Display (Voice Alerting & Peaks)
G-Meter Display (Voice Alerting & Peaks)
Attitude (Roll / Pitch)
Slip / Skid Indication
Clock (GMT / Local)
Outside Air Temperature (C / F)
Bus Voltage Display
Dual User Timers (Count Up / Down)
Engine Run Timer
Flight Timer
Density Altitude Display
True Airspeed Display (Kts / Mph)
Internal Battery Operation (30 Min)

Also Purchased

Specifications

tailBeaconX Specifications:
Weight:

140 grams
Size:

113x105x48mm
Input Voltage:

11-31V DC
Operating Power:

3 Watts
SDA/SIL:

2/3
Operating Temp:

-45°C to 70°C
1090ES ADS-B Transmitter:

Power Classification 250 Watts Nominal
WAAS GPS:

Tracking - 166dBm Reacquisition -1 60dBm Cold Start - 148dBm
LED Position Light:

Color - Aviation White Intensity - 20 candelas
Control Head:

Physical - RS232 or Power Line Modem Protocol - UCP
AV-30E Specifications:
Weight:

0.50 lb
Dimensions:

3.38 x 3.38 x 1.6 in.
Input Voltage Nominal:

+10 to +32 VDC
Input Voltage Max:

+60 VDC
Input Power Nominal:

6 Watts (0.5 Amps @ 12VDC)
Input Power Max:

12 Watts (1.0 Amps @ 12VDC)
Required Circuit Breaker:

2 Amp
Operation on Battery:

2 Hours Typ. @ 20°C / 30 Minutes Min @ -20C
Mounting Configuration:

3 1/8” Round Instrument Hole Electrical Connector: 15 Pin Male D-Sub
Pneumatic Connectors:

1/4 in. OD Quick Connect
Mounting:

(4X) #6-32 Machine Screws
Case Material:

Billet Aluminum
Operating Temp:

-20°C to +55°C
Diagonal Size:

3 in (circular)
Contrast Ratio:

(Typical) 500
Brightness:

(Typical) 1000 cd/m2
Viewing Angle Left/Right:

60°
Viewing Angle Up:

45°
Viewing Angle Down:

10°
Backlight Lifetime:

(Typical) 50,000 hr
