SAFE 528 Cooling Fan | 22–31 VDC, 5-Port, 400 mA

Product Description

The SAFE 528 is able to cool up to five avionics units with up to 20 cubic feet of cooling air per minute. It operates on 22–31 VDC and maintains avionics equipment at proper operating temperature. These cooling fans use high quality, brushless blower motors and use RunQuiet technology. These units are FAA PMA approved and pass stringent environmental testing to ensure years of reliable service.

Specifications

• Weight:
  1.19 lb
• Dimensions:
  6.77 x 5.13 x 2.10 in
• Current Draw:
  Operating: 400 mA nominal Startup: 550 mA
• Operating Voltage:
  22-31 VDC
• Air Flow:
  20 CFM No Static Pressure
• Operating Temp:
  -20°C to 55°C

Product Codes

• Mfr Part No
  705722-00
• ECCN
  7A994
• PMA
  PQ0894SW
• SCHEDULE B CODE
  8414.59.9080

Documentation

• SAFE528 Installation Manual
