50-Pin D-Sub Connector | Male, 3-Row, RoHS

Product Description

This male, D-sub connector (EDMO# 1658641-3) is a 50-pin connector with three rows of pins and RoHS compliant.

Specifications

• Dimensions:
  Wire size: 0.2 – 0.56 mm2 (24 – 20 AWG)
• Cable Insolation Diameter:
  4.58 – 11.68 mm
• Temperature:
  -55°C to 105°C (-67°F to 221°F)
• Connector style:
  plug
• Connector system:
  cable-to-cable
• Number of Positions:
  50-pin
• Contact Size:
  20
• Shell Size
  : 5
• Body Insert Material:
  glass-filled nylon
• Body shell plating material:
  zinc
• Body shell material:
  steel

Product Codes

• Mfr Part No
  16586413, 205212-1
• CSA
  LR 1088108, LR7189-207
• ECCN
  EAR99
• ROHS
  YES
• SCHEDULE B CODE
  8536.90.4000
• UL
  E28476, E81956
