Airman 8+ ANR Headset | Dual PJ Connector, 600Ω

Product Description

The Telex Airman 8+ is a lightweight noise-reducing headset designed specifically for optimizing pilot communications in commercial and business turbine aircraft. Building on the tradition of the Airman 850 and the Airman 8, Airman 8+ has improved ANR capability and comfort.

The Airman 8+ is among the lightest Active Noise Reduction headsets on the market and one of only three FAA TSO-C139a approved ANR headsets to utilize Telex’s proprietary battery-free system. Larger pliable ear cushions and headband pad combined with dual-axis ear cup pivots to provide long flight wearing comfort.

This Airman 8+ headset (EDMO# 8P-0210) is double-sided, with a dual PJ-068 and PJ-055 connector, and has a 600Ω impedance. (*Pictured with a large headband pad).

Specifications

• Weight
  : 6.7 oz with cord
• Cord Length:
  6 ft ± 4 in
• Color:
  Black/Stainless Steel
• Connector:
  Dual PJ Connector (Headphone: PJ-055 & Microphone: PJ-068)
• Headphone Type:
  Dynamic
• Headphone Impedance:
  600Ω ±20% @ 1 kHz
• Headphone Frequency Response:
  (Per RTCA DO-214a) <15dB max. to min. over the range of 315 to 3150Hz
• Headphone Sensitivity:
  (Per RTCA DO-214a) 92 ±5 dBSPL (normal) 98 ±5 dBSPL (high)
• Microphone Element:
  Noise-canceling amplified electret
• Microphone Sensitivity:
  (Per RTCA DO-214a) -28dB ±3dB re 1V/Pa at 1kHz, 12V
• Microphone Operating Voltage:
  (Per RTCA DO-214a) 8-28 VDC (470 Ω load circuit)
• ANR Power:
  Via boom microphone connection
• Controls:
  Active Noise Reduction On/Off Switch Volume Normal/High Switch

Product Codes

• Mfr Part No
  AIRMAN8P-0210
• ECCN
  7A994
• PROAPP
  PT4047CE
• SCHEDULE B CODE
  8518.30.2000
• TSO
  C139a

Documentation

• Airman 8+ Technical Data Sheet
• Airman 8+ Operation Manual
