Heavy Duty In-Line Fuse Holder | 14AWG, 15in Loop, Red Wire

Product Description

Universal Glass Bayonet Knob In-line Fuse holder constructed of tough black thermoset (UL94V0). Includes 3 springs for various fuse sizes and spring-locked, bayonet type knob. Supplied with 15in loop of 14 gauge red wire. Use with Glass SFE 71/2, 9, 14, 20, AGA, AGC, AGW and AGX Fuses up to 20 amps when proper spring is installed.

Specifications

• Wire length:
  15 in. loop
• Wire size:
  14 AWG
• Wire color:
  Red
• Fuse size:
  1/4 in.
• Amps:
  20A
• Voltage:
  600 VAC/DC max
• Molded parts:
  Body and knob are black thermoset (UL94-V-0)
• Lock type:
  Bayonet

Product Codes

• Mfr Part No
  0FHP0001Z
• ECCN
  EAR99
• SCHEDULE B CODE
  8536.10.0020
• UL
  UL94V0
