M22759/16 Extruded ETFE Tefzel Wire | 22 AWG, Gray

M22759/16 Extruded ETFE Tefzel Wire | 22 AWG, Gray

HELISTRAND

EDMO#: 22G/16-8

MFR#: M22759/16-22-8

Call for Pricing

Call us at (800) 235-3300 to purchase

In Stock

Also Purchased

Description

SAE AS22759 wire is a fluoropolymer insulated, single-conductor wire offering excellent performance for a variety of military aerospace and commercial applications. It has high performance and reliability in severe wind and moisture prone (SWAMP) zones such as engine nacelles as well as areas requiring overload stability, low smoke emission and fire resistance, such as aircraft cabins.

SAE AS22759/16 wire is designed for aerospace applications for commercial and military aircraft. It has a stranded tin-plated, copper conductor, Extruded ETFE dielectric, a rating of 600 volts and 150°C.

Features

This M22759/16 tefzel hook-up wire (EDMO# 22G/16-8) has a tin-plated, copper, 22 AWG conductor with extruded ETFE insolation, and colored gray.

  • 600 volt rating
  • 150C temperature rating
  • Excellent thermal stability
  • High reliability
  • High break strength and flex life
  • High abrasion resistance

Specifications

AWG:
22 AWG

Stranding:
19/34

Conductor Diameter:
0.030 in

Insulation Diameter:
0.050 - 0.054 in

Weight:
3.52 lb/mft

Max. Resistance @ 20°C:
16.2 Ω/MFT

Product Codes

Mfr Part No :

M22759/16-22-8

MIL SPEC :

M22759/16-22-8

ECCN :

EAR99

MIL SPEC :

M22759/16-22-8

SCHEDULE B CODE :

8544.11.0050

Notice: EDMO Distributors, Inc. has made every effort to verify the accuracy of the codes, classifications, and part approvals listed in accordance with the Department of Commerce, U.S. Census Bureau, Bureau of Industry and Security, U.S. Department of Defense and Federal Aviation Administration. EDMO Distributors, Inc. does not assume responsibility for errors or omissions. This listing is subject to change without notice.

Warning to Exporters: EDMO Distributors, Inc. does not assume responsibility for errors with any of the Schedule B Commodity Codes or Export Control Classification Numbers in this listing. It is the Exporter's responsibility to research and supply the correct codes and classifications for the product to be exported. Some products may require an Export License in order to be exported.
