M27500-22SD1T14 Modified ETFE Tefzel Wire | 22 AWG, 1 Conductor

Product Description

SAE AS22759 wire is a fluoropolymer–insulated, single-conductor wire offering excellent performance for a variety of military aerospace and commercial applications. It has high performance and reliability in severe wind and moisture prone (SWAMP) zones such as engine nacelles as well as areas requiring overload stability, low smoke emission and fire resistance, such as aircraft cabins.

M27500-22SD1T14 meets SAE AS22759/34 specifications and has a cross-linked, modified ETFE insulation surrounding an aromatic polyimide braid which provides EMI/RFI shielding and features a tin-plated, copper conductor with a temperature rating of 150°C — offering both flexibility and durability.

This M27500-22SD1T14 Tefzel wire (EDMO# 22SD1T14) has a single tin-plated 22 AWG conductor, modified ETFE insulation.

Specifications

• Weight:
  3.2 lb/mft
• Gauge:
  22 AWG
• Stranding:
  19/34
• Conductor Diameter:
  0.029 in
• Insulation Diameter:
  0.031 to 0.050 ±0.002 in
• Max. Resistance (@ 20°C)
  16.2 Ω/mft

Product Codes

• Mfr Part No
  M27500-22SD1T14
