ProFIT® HIX Heat Shrink Tubing | White, 3/64 in, 4 ft

ProFITÂ® HIX Heat Shrink Tubing | White, 3/64 in, 4 ft

ICO RALLY

Call For Pricing

In stock

EDMO # HIX-3/64WH

MFR Part # HIX-3/64 WHITE

Need help placing an order? Call 800-235-3300 or Contact us

Product Description

ProFIT® HIX general purpose polyolefin heat-shrinkable tubing is used for insulating, jacketing, bundling, and identifying wire and cables. HIX tubing is mechanically tough and resistant to abrasion and solvents while providing a longitudinal shrinkage less than 6%.

This HIX heat shrink tubing (EDMO# HIX-3/64WH) has a 3/64 inch diameter, colored white, and comes on a 4 foot stick.

Features

Application specifications: SAE-AMS-DTL-23053/5, Class 1 and 2
UL File Number: E52612 (VW-1 except Clear)
Operating Temperature: -67°F to 275°F (-55°C to 135°C)
Shrink Ratio: 2 to 1
Shrink Temperature: 250°F (121°C)
Color: white (other colors available)

Also Purchased

Specifications

Diameter:

3/64 in
Length:

4 ft per stick
Minimum Expanded I.D.:

0.046 in (1.17 mm)
Maximum Recovered I.D.:

0.023 in (0.58 mm)
Recovered Wall Thickness:

0.016 in (0.40 mm)

Product Codes

Mfr Part No

HIX-3/64 WHITE
MIL SPEC

M23053/5
ECCN

EAR99
MIL SPEC

M23053/5
SCHEDULE B CODE

3902.30.0000
