Gripper Wireless Bridle Cable Tension Meter | 60lb

Sprague Instruments

Call For Pricing

Available to order

EDMO # CTRBCWL60

MFR Part # CTR-BCWL-30

Need help placing an order? Call 800-235-3300 or Contact us

Product Description

The Gripper Digital Cable Tension Meter provides technicians a simple method for maintaining correct cable tension in autopilot flight control systems and is small enough to fit into tight areas. The small sensor head and separate handheld display box make it easier to view the measurement readings while adjusting the cable tension. The informative display box screen shows the temperature, cable size, and battery strength. This tensiometer is simple to use and has no extra parts. The unit comes calibrated, certified, and ready to use out of the box. Just turn on the unit and select the correct cable size. The Gripper has been designed so local calibration shops can certify their tools using the calibration information that is specified in user manuals.

This Gripper tensiometer (EDMO# CTRBCWL60) has a 10–60 lb range for testing autopilot bridle cables and supports 1/16, 3/32, and 1/8 inch cable sizes.

Features

Selectable units of measurement ºC and ºF
Compact sensor head fits into tight spaces
Display screen shows temperature, cable size, and battery strength
Works for a range up to 10 meters
±3% of Full scale Tolerance
10 to 60 pound range
Back light ON/OFF display option
Connects wirelessly via Bluetooth
Carrying case included

Specifications

Scale Range:

10–30 lb
Scale Resolution:

1 lb
Scale Tolerance:

±3% of Full scale
Unit of Measurement:

Metric – Kg, 0°C U.S. Standard – lb , 0°F
Supported Cables Sizes:

1/16, 3/32, 1/8 in
Ambient Temperature:

Selectable ºC and ºF
Operating Temperature Range:

14°F to 100°F (-10°C to 40°C)
Storage Temperature:

-4°F to 122°F (-20°C to 50°C)
Operating Modes:

Measurement / Calibration / Firmware Update
Humidity:

5 to 95 %
Communication:

BLE 4.2 (Between Display Unit & Sensor Unit)
Wireless Range:

10 meters
Display Unit Weight:

160 gm (approx.) Housing ABS Plastic
Display Unit Dimensions:

164 x 80 x 29 mm
Display:

160 x 128 Dot Matrix LCD Back light ON/OFF option
Charging:

5V DC / Charge Status Indicator 1,500mAH – Li Po Rechargeable Battery ~10,000 Readings on a single charge with the backlight OFF ~3,000 Readings on a single charge with the backlight ON
Sleep mode:

Activated after 5 Mins of inactivity
Sensor Voltage Weight:

240 gm (approx.)
Sensor Voltage Dimension:

2.5 x 1.25 x 1.5 in
Charging Voltage:

5VDC / Charge Status Indicator
Power:

500mAH – Li Po Rechargeable Battery ~4,000 Readings with a Single Charge Sleep mode after 5 mins idle time
Housing:

6061 Aluminum
