CPC Cable Clamp | #23 Shell Size, 17.86mm Cable Diameter
Product Description
CPC cable clamp kits provide excellent strain relief and can used on all series of CPC receptacles and plugs.
This CPC clamp kit (EDMO #206138-8) features a straight, #23 shell size, fits cables with a diameter of 17.86 mm, has a 1-3/8-18 UNEF-2B thread size, and 0.500 inch screw length.plastic Cable Clamp Material
Features
- Constructed from heat-stabilized, black thermoplastic
- Fire resistant and self-extinguishing
- UL 94V-0 rated
- ROHS Compliant
Specifications
Dimensions:
1.6 x 1.555 in (40.64 x 39.5 mm)
Cable Diameter:
0.703 in (17.86 mm)
Shell Size:
23
Thread Size:
1-3/8-18
Flammability Rating:
UL 97 V-1
Mounting Angle:
Straight
Connecter Type:
CPC Standard Circular Connector
Shell Material:
Thermoplastic
Product Codes
- Mfr Part No:206138-8
- EDMO #:206138-8
- Brand:TE CONNECTIVITY
- Category:Wire, Cable & Accessories
- CSA:FILE NO.1088108, LR:7189-207
- ECCN:EAR99
- MIL SPEC:MIL-C-24308
- MIL SPEC:MIL-C-24308
- MIL SPEC:MIL-C-24308
- SCHEDULE B CODE:8536.90.4000
- UL:E81956
