TJ-102 4-Conductor In-Line Telephone Jack

Product Description

The TJ-102 in-line jack has four conductors and constructed to accommodate larger cable diameters. Mates with Nexus series TP-120, TP-101, TPSJ-101, and TP-102 plugs.

Specifications

• Dimensions:
  0.828 x 0.828 x 2.312 in
• Number of Conductors:
  4
• Shell Material:
  plastic
• Contact Material:
  nickel-plated, beryllium copper
• Standard:
  MIL-C-9177
• Solder Contact Terminals:
  Pre-tinned over nickel plating
• Contact Resistance:
  ≤ 0.02 Ω
• Insulation Resistance:
  ≥ 1,000 mΩ
• Dielectric Withstanding Voltage:
  ≥ 500 V RMS
• Insertion Force:
  13 lb, maximum
• Withdrawal Force:
  6 to 10 lb
• Application:
  ruggedized commercial & military

Product Codes

• Mfr Part No
  TJ-102
• MIL SPEC
  M9177/3-1
• ECCN
  EAR99
• MIL SPEC
  M9177/3-1
• SCHEDULE B CODE
  8536.69.4020

Documentation

• TJ-102 Drawing
