.206-inch Cable Mount Jack | 3-Conductor, Screw terminals, Stereo

JJ033 INLINE JACK/or VE068J

SWITCHCRAFT

Call For Pricing
In stock
EDMO # SWC S830
MFR Part # SWC S830
Need help placing an order? Call 800-235-3300 or Contact us

Product Description

Switchcraft .206-inch jack connectors are designed for applications requiring polarization to prevent insertion of incorrect equipment. These Littel Plug® phone plugs feature a sleeve and a tip diameter of .206 inches.



This .206 cable mount jack (EDMO# SWC S830) has a 3-connector stereo plug, screw terminals and a black handle. Mates with Switchcraft 480 MIL TYPE 3-conducter .206 inch plug.

Features

  • Nickel-plated, brass body
  • Nickel silver tip & ring terminal
  • Electro-tinned brass clamp terminal
  • Nickel-plated screws
  • Black nylon handle
  • RoHS compliant

Also Purchased

Specifications

  • Dimensions:
    2.12 x 0.75 in
  • Jack Diameter:
    0.210 in
  • Plug Diameter:
    0.210 in
  • Insertion Force:
    7 lb
  • Withdrawal Force:
    1 lb
  • Contact Resistance:
    0.030Ω, maximum
  • Insolation Resistance:
    10,000 MΩ
  • Dielectric withstanding Voltage:
    500V, 60 Hz (rms) AC
  • Contact Rating:
    1A, 25 VDC

Related Products

Product Codes

  • Mfr Part No
    SWC S830
  • ECCN
    EAR99
  • SCHEDULE B CODE
    8536.69.4030
