QUICK SHOT Avionics Installation Reference Manual | Vol 1, Rev 6


EDMO DISTRIBUTORS, INC

CALL FOR PRICING
In Stock
EDMO#QSMANR6
MFR#QSMANR6

Need help placing an order?
Call 800-235-3300 or Contact Us

Product Description

The newly revised QUICK SHOT Avionics Installation Reference Manual has 334 pages of detailed wiring diagrams covering more than 50 manufacturers. Reference popular and legacy connectors with accurate pin designations. Individual pages contain bold manufacturer titles with model numbers, illustrations, specifications, schematics, and special case notes.

Features

  • Volume 1, revision 6
  • Over 50 manufacturers
  • Easy to find alphabetical sections
  • 6-ring vinyl wrapped binder
  • Easy open ends
  • Overlapping cover with velcro closure
  • Pen holder

Specifications

Dimensions:
7.375 x 5.375 x 1.5 inch

Pages:
334

Binder:
Hard cover vinyl wrapped 6-ring

Product Codes

  • Mfr Part No:QSMANR6
  • EDMO #:QSMANR6
  • Brand:EDMO DISTRIBUTORS, INC
  • Category:Books & Training
