N Male to C Female RF Adapter | 50Ω, Straight Body Geometry
Product Description
RF adapters are often used to enable connections between two connector types that would otherwise not mate. Certain adapter configurations can also be used to protect connectors on expensive equipment where the number of connect/disconnect cycles is high. An RF, microwave or millimeter wave adapter is connected to the equipment, and the commonly changed connection is made with the adapter which can be easily replaced when it wears out after high usage.
This RF adapter (EDMO# PE91446) is an N male to C female adapter with a straight body geometry.
Features
No product features currently available.
Specifications
Weight:
0.103 lb (46.72 g)
Dimensions:
1.464 x 0.83 x 0.83 in (37.19 x 21.08 x 21.08 mm)
Frequency Range:
DC to 11 GHz
Operating Voltage:
1000 Vrms
Dielectric Withstanding Voltage:
2500 Vrms
Insulation Resistance:
5,000 MΩ
Operating Range:
-65°C to 165°C
Impedance:
50Ω
Connector Types:
N Male to C Female
Polarity:
Standard
Contact Material:
Gold Plated Beryllium Copper
Body Material:
Nickel Plated Brass
Product Codes
- Mfr Part No:PE91446
- EDMO #:PE91446
- Brand:PASTERNACK
- Category:Electrical Interconnect
