Military Amplified GPS Antenna Splitter | 1 Input, 2 Outputs, TNC Connector, Mil-Spec
Product Description
This military qualified amplified GPS antenna splitter features a loaded DC blocked, one input and two outputs for splitting RF signals from 1.1 GHz to 1.7 GHz. This splitter is designed to amplify and split signals with the L-band frequency range to provide multiple devices with signal a single antenna. In the standard configuration, the J1 port passes DC voltage from a connected device to the antenna or another device up from the splitter. The other port J2, is DC blocked and loaded with a 200Ω resistor to simulate antenna current draw which prevents alarm faults. Mil-Spec splitters are qualified to the rigorous MIL-STD 810F environmental & MIL-STD EMI standards.
This military amplified GPS splitter (EDMO# MIL-ALDCBS) features 1 input and two outputs, and TNC type connectors. Mil-Spec Qualified.
Features
- Excellent amplified balance: < 1 dB variation between ports
- Flat group delay: <1 ns variation between L1 & L2
- High output gain: 22 dB typical across operating frequencies
- Wide accepted frequency range: entire L-band & major GNSS constellations
- Efficiently blocked ports: 200Ω resistor prevents antenna alarm faults
- Matched phase balance: <4° variation between ports
- Qualifications & test reports available
Specifications
Weight:
10.2 oz (289 g), max.
Dimensions:
1.3 x 3.25 x 2.5 in, max. (not including connectors)
Operating Temperature:
-57°C to 87°C
Frequency Range:
1.1 GHz — 1.7 GHz
Characteristic Impedance:
50Ω
Req. DC Input V.:
3.3 VDC — 15 VDC
Input P1dB:
-24 dBm
Current Draw:
23 mA
Gain:
21 dB — 23.5 dB (22 dB, typical)
Input SWR:
2.0:1, max.
Output SWR:
2.0:1, max.
Noise Figure:
L1: 2.3 dB, typical (2.5 dB, max.)
L2: 4.7 dB, typical (5.0 dB max.)
Gain Flatness:
0.5 dB, typical (1 dB, max.)
Amplitude Balance:
0.25 dB, typical (1.0 dB, max.)
Phase Balance:
4.0°, max.
Isolation:
L1: 22 dB, min.
L2: 15 dB, min.
Group Delay Flatness:
0.5 ns, typical (1 ns, max.)
Connector Option:
TNC type
Product Codes
- Mfr Part No:MIL-ALDCBS1X2-T
- EDMO #:MIL-ALDCBS
- Brand:GPS NETWORKING
- Category:GPS Components & Accessories
