MD41 Series TAWS Annunciation Control Unit | 28V, Vertical, Sandel ST3400
Product Description
The MD41 TAWS Annunciation Control Unit is a two-button vertical 28 volt TAWS for Honeywell KGP 560/860. Designed to place annunciation and mode selection for the Terrain Awareness Warning System (TAWS) within the pilots direct field-of-view, these annunciators provide tactile feedback to the pilot through internally-lighted push buttons.
Version (EDMO# MD41-1258) is a 28V unit with vertical orientation compatible with Sandel ST3400.
Features
- Control unit provides annunciation and mode selection for TAWS (Terrain Awareness Warning System) and EGPWS (Enhanced Ground Proximity Warning Systems)
- Presents primary or secondary visual alert of TAWS within the pilot’s direct field of view
- Single cutout
- Panel punches available
- Easy-to-wire D-subminiature connector
- Proven daylight-readable annunciations with automatic photocell dimming
- Internally lighted push-buttons provide firm tactile feedback to the pilot
- Remote annunciator test capability
- Certified to TSO C151a
- Meets RTCA DO-160D environmental specifications (certified to 55,000 feet)
- Quality Mil-Spec connector included
Specifications
Weight:
0.50 lb
Dimensions:
2.75 x 3.22 x 0.80 in.
Temperature:
-55ºC to +70ºC
Humidity:
95% non-condensing
Altitude:
55,000 ft
Product Codes
- Mfr Part No:MD41-1258
- EDMO #:MD41-1258
- Brand:MID-CONTINENT INSTRUMENTS AND AVIONICS
- Category:GPS Components & Accessories
