Low Noise Filtered Amplified GPS Splitter | 1 Input, 4 Output, TNC Connector
Product Description
This low noise amplified GPS splitter features one input and four outputs for distributing filtered L1 GPS frequencies indoors with a nominal 0 db gain. A low noise input provides an excellent overall system noise figure. Padded outputs provide excellent port-to-port isolation and unity gain. Excellency frequency selection of the L1 band prevents interference from other high power radio sources. A five-volt power source connected on any of the RF output will power the splitter as well as an external GPS antenna. If multiple DC sources are connected then a ""pick and choose"" circuit will select one source to power the system, and the remain ports are switched to a 200Ω resistor to prevent antenna alarm faults.
This low noise filtered amplified GPS splitter (EDMO# LNFA1X4-T) has one-input & two-outputs, and has TNC connectors.
Features
- Low Noise
- Amplified unity gain 0 dB (typical)
- Filters L1 GPS frequency band
- Extremely flat group delay: <1 ns variation between ports
- High isolation between ports
- 200Ω loads block DC preventing antenna alarm faults
- Excellent gain flatness
Specifications
Weight:
20.9 oz (593 g)
Dimensions:
1.4 x 6.75 x 2.5 in, max. (not including connectors)
Operating Temperature:
-57°C to 87°C
Frequency Range:
1.1 GHz — 1.7 GHz
Characteristic Impedance:
50Ω
Req. DC Input V.:
3.3 VDC — 6 VDC
Current Draw:
7 mA
Gain:
-1.5 dB to 1.5 dB
Input SWR:
2.0:1, max.
Output SWR:
2.0:1, max.
Filter Bandwidth:
30 MHz, typical
Rejection:
-60 dB, typical
L1 Noise Figure:
4.75 dB, typical
Amplitude Balance:
1.0 dB, max.
Phase Balance:
6°, typical
Isolation:
50 dB, typical (>61 dB, max.)
Input P1dB:
-31.5 dBm
Connector Option:
TNC type
Product Codes
- Mfr Part No:LNFA1X4-T
- EDMO #:LNFA1X4-T
- Brand:GPS NETWORKING
- Category:GPS Components & Accessories
