INX 760 Probe Microscope Kit
Product Description
The INX 760 is the ultimate tool for field technicians, offering unparalleled efficiency in ensuring pristine fiber connections. As the culmination of over 25 years of pioneering innovation and expertise, it stands as the apex of next-generation fiber end face inspection and analysis. While fiber inspection has become a standard practice for many field technicians, contamination still continues to be the #1 cause of optical network problems. With new connector types emerging, greater connector volumes used in the field, and an increase in new fiber technicians, the industry has reached an inflection point, causing the need for a new inspection solution – the INX 760.
The INX 760 Probe Microscope Kit (EDMO# INX760KIT2) includes the INX 760 Microscope with Automated Simplex Multifiber Inspection and BT Wi-Fi Connectivity, bulkhead tips for MPO/PC, MPO/APC, LC/PC, LC/APC, SC/PC, SC/APC, mating adapters for MPO, LC duplex, SC duplex, tip cover, tip storage case, USB charging adapter and cable, and a carrying case.
Features
- True Automated Inspection delivers the industry’s fastest workflow for user applications that automates every step of the inspection process.
- AutoID Inspection Tips eliminate mistakes of error-prone manual or RFID configuration when changing tips.
- PanOptic Imaging Engine ensures edge-toedge field-of-view without compromising magnification and resolution quality.
- VIAVI TPA Enabled, ensuring alignment, efficiency, and accuracy at every stage of a job with Test Process Automation.
Specifications
Weight:
1.5 lb (0.665 kg) without a tip
Dimensions:
9.9 x 7.5 x 2.4 in (253 x 191 x 60 mm) without a tip
Field of View:
Multifiber: 6400 x 1425 μm
Simplex: 1000 x 1425 μm
View Modes:
Live, Inspected
Magnification Modes:
Low, High (auto center)
Focus:
Auto (on insert, triggered), Manual (simplex, duplex)
Panning:
Auto (duplex, multifiber), Manual (multifiber)
Image Analysis:
Auto: IEC 61300-3-35 edition 2, IEC 61300-3-35 edition 3
Test Results:
Save: triggered, auto if pass, auto always
Simplex: ≤ 10,000, Duplex: ≤ 5,000, MPO 12x1: ≤ 1,500 saved
Or proportional combination of the above
Auto Focus + Pan + Analysis:
Simplex: ≤4 s, Duplex: ≤5 s, MPO 12x1: ≤8 s
Auto Save:
Simplex: ≤1 s, Duplex: ≤1 s, MPO 12x1: ≤2 s
Hard Buttons:
Power, trigger, wheel
Display:
320 x 240-pixel (2.4 in) color backlit touch screen
Status Indicators:
LED ring, power/battery charging LED, speaker
Power Supply:
5V/2.1A USB AC adapter
Battery:
Li-ion (field serviceable)
Operating Time:
> 4 hr (1 MPO 12x1 test + save/min)
Wired Connectivity:
USB-C port with optional locking mount
Wireless Connectivity:
Bluetooth® 5.2 BLE, Wi-Fi 802.11b/g/n
Mounting Point:
¼ inch diameter, 20 threads per inch (1/4-20) socket
Operating Temperature:
32 to 104°F (0 to 40°C)
Storage Temperature:
-4 to 140°F (-20 to 60°C)
Operating Humidity:
0 to 90% non-condensing
Product Codes
- Mfr Part No:INX-760-KIT2
- EDMO #:INX760KIT2
- Brand:VIAVI
- Category:Fiber Optic Inspection
