Product Description

Icom’s IC-A120 VHF Airband Mobile Transceiver introduces two features: Active Noise Cancelling (ANC) and Bluetooth® capabilities. The built-in ANC reduces background noise and is effective in extremely noisy airport environments. The automatic noise limiter (ANL) reduces pulse-type noise such as engine ignition.

The IC-A120 also features an ON-Hook scan function that automatically starts scanning when the hand microphone is hooked on the microphone hanger. When a user takes the microphone OFF hook, the scanning stops at the priority channel or displayed channel. A Dualwatch function checks the priority and operating channels alternatively. Meets IP54 standards for dust protection and water-resistance.

This version (EDMO# IC-A120B) includes a base station with a 120-volt power supply and hand microphone.

Features

Includes:
Base station cabinet
Hand microphone (HM-216)
DC power cable
Microphone hanger kit
Mounting bracket kit
Fuses
Features:
Dot-matrix LCD display is easy to read with crisp, clear text
Memory channels and other radio settings can be programmed from the front panel
Provides 200 memory channels with 12-character channel names and 8.33 kHz and 25 kHz channel spacing
Built-in Active Noise Canceling (ANC) reduces background noise in the received and transmitted signals
Automatic noise limiter (ANL) reduces pulse-type noise such as engine ignition (ANL and ANC functions cannot be used at the same time)
IP54 dust-protection and water-resistant construction allows the IC-A120 to be used in open-air vehicles
ON-Hook scan function automatically starts scanning when the hand microphone is hooked on the microphone hanger
Dualwatch feature checks the priority and operating channels alternatively while ON-Hook
Provides optional Bluetooth® headset connectivity when the UT-133 Bluetooth unit is added — allowing for third-party wireless Bluetooth headsets to be used
Third-party headsets can be used with the optional OPC-871A headset adapter
Optional HM-217 speaker-microphone allows the user to listen to received audio through the HM-217’s built-in speaker
The speaker-microphone features up/down buttons as well as two programmable P1/P2 buttons that serve as a shortcut for activating frequently used functions
Compatible with 12- and 24- volt systems
36W (PEP) RF output power
Power-on password protection
PC programming capability
CI-V Commands for external control
VE-PG3 RoIP gateway for interconnecting with other radio devices

Also Purchased

Specifications

Weight:

3.3 lb (1.5 kg)
Dimensions:

6.3 x 1.8 x 6.9 in (161 x 45 x 175 mm)
Frequency Range:

118 MHz - 136.99166 MHz, (IC-A120) 118 MHz - 136.975 MHz, (ICA120E)
Channel Spacing:

25 kHz, 8.33 kHz
Type of Emission:

6K00A3E/5K60A3E (FCC/EXP), 6K00A3E (Industry Canada), (IC-A120) 6K80A3E/5K00A3E, (IC-A120E)
Number of Memory Channels:

200
Antenna Impedance:

50Ω, nominal
Antenna Connector:

SO-239
Power Supply Requirement:

13.75VDC / 27.5VDC, negative ground
Current Drain (13.75 VDC):

5.0A, Tx 4.0A, maximum audio
Operating Temperature:

-22°C to 140°F (-30°C to 60°C), (IC-A120) -20°C to 55°C, (IC-A120E)
TRANSMITTER

Output Power: 9 watt, carrier power, typical (IC-A120) 9 watt, ±1.5dB, (IC-A120E)
Frequency Stability:

±5 ppm (IC-A120) ±1 ppm (IC-A120E)
Modulation System:

Last stage modulations
Audio Frequency Distortion:

<10% @ 70% modulation (IC-A120) <10% @ 85% modulation +3dB (IC-A120E)
Spurious Emissions:

< -60dBc (IC-A120) 9 kHz to 30 MHz: < –46 dBm (IC-A120E) 30 MHz to 1 GHz: < –36 dBm (IC-A120E), for harmonics 1 GHz to 4 GHz: < –30 dBm (For Harmonics), < –40 dBm (For Non-Harmonics)
RECEIVER

Receiver System: Double conversion superheterodyne
Intermediate Frequencies:

1st: 38.85 MHz 2nd: 450 kHz
Sensitivity:

<1 µV (pd), @ 6dB S/N, (IC-A120) < -101 dBm, 12dB SINAD with CCITT, (IC-A120E)
Squelch Sensitivity:

< 0.35 µV (pd), (IC-A120) < -116 dBm, (IC-A120E)
Spurious Response Rejection Ratio:

> 5 mV (pd), (IC-A120) > 70 dBm, (IC-A120E)
Audio Output Power:

External Speaker: > 10 watts, @ 13.75 VDC with 8Ω load Side tone: > 100 mW, @ 13.75 VDC with 500Ω load
