L1 GPS Hangar Networked Re-Radiating Kit | 110V, N Connector
Product Description
The HNRRKIT hangar network system re-radiates a GPS L1 signal indoors creating a perfect environment for a custom GPS network. The re-radiating amplifier is able to receive a GPS line of sight signal up to 100 feet. The HNRRKIT110 consists of an active roof antenna, a re-radiating amplifier with a wall mount plug-in transformer that powers the entire system, and a passive re-radiating antenna.
This product is only to be used for testing GNSS equipment/systems for the purpose of product development or fabrication.
Per the latest FCC guidance, the following use cases are NOT allowed:
- Fire Stations & First Responders
- Aircraft Repair and Maintenance
- Truck Repair and Maintenance
- Any other usages which could be considered "maintenance".
An FCC Experimental Broadcast license is required to operate this device, with the following exceptions:
- Device is operated in a shielded environment, such as an anechoic chamber.
- Device is operated in conjunction with a reradiating hood.
- Device is operated by federal or DoD personnel with the approval of the local spectrum manager.
Features
Kit Includes:
- 110V amplifier
- L1 roof antenna
- Re-radiating antenna
- Power supply
Features:
- N-female connector
- Compatible with antenna mounts (not included)
- 100 ft indoor line of sight GPS signal reception
- Wall mount plug-in transformer powers entire system
Specifications
Frequency range:
1.1 GHz min, 1.7 GHz max
In/out impedance:
50 Ω
Gain:
29 dB min, 31 dB max
Input SWR:
1.8:1 dB max
Output SWR:
1.8:1 max
Noise figure:
3.5 dB max
Gain flatness:
1 dB max
Reverse isolation:
35 dB min
Product Codes
- Mfr Part No:HNRRKIT-N/5/110
- EDMO #:HNRRKIT110
- Brand:GPS NETWORKING
- Category:GPS Components & Accessories
