ProFIT® HIX Heat Shrink Tubing | White, 2 in, 100 ft
Product Description
ProFIT® HIX general purpose polyolefin heat-shrinkable tubing is used for insulating, jacketing, bundling, and identifying wire and cables. HIX tubing is mechanically tough and resistant to abrasion and solvents while providing a longitudinal shrinkage less than 6%.
This HIX heat shrink tubing (EDMO# HIXR-2WH) has a 2 inch diameter, colored white, and comes on a 100 foot roll.
Features
- Application specifications: SAE-AMS-DTL-23053/5, Class 1 and 2
- UL File Number: E52612 (VW-1 except Clear)
- Operating Temperature: -67°F to 275°F (-55°C to 135°C)
- Shrink Ratio: 2 to 1
- Shrink Temperature: 250°F (121°C)
- Color: white (other colors available)
Specifications
Diameter:
2 in
Length:
100 ft roll
Minimum Expanded I.D.:
1.500 in (38.10 mm)
Maximum Recovered I.D.:
0.750 in (19.05 mm)
Recovered Wall Thickness:
0.040 in (1.01 mm)
Product Codes
- Mfr Part No:HIX-2
- EDMO #:HIXR-2WH
- Brand:ICO RALLY
- Category:Wire, Cable & Accessories
