ProFIT® HIX Heat Shrink Tubing | Black, 1/8 in, 100 ft

ProFIT® HIX Heat Shrink Tubing | Black, 1/8 in, 100 ft

Product Description

ProFIT® HIX general purpose polyolefin heat-shrinkable tubing is used for insulating, jacketing, bundling, and identifying wire and cables. HIX tubing is mechanically tough and resistant to abrasion and solvents while providing a longitudinal shrinkage less than 6%.

This HIX heat shrink tubing (EDMO# HIXR-1/8) has a 1/8 inch diameter, colored black, and comes as a 100 foot roll.

Features

No product features currently available.

Specifications

Diameter:
1/8 in

Length:
100 ft roll

Minimum Expanded I.D.:
0.125 in (3.18 mm)

Maximum Recovered I.D.:
0.063 in (1.60 mm)

Recovered Wall Thickness:
0.020 in (0.50 mm)

Operating Temperature:
-67°F to 275°F (-55°C to 135°C)

Shrink Ratio:
2 to 1

Shrink Temperature:
250°F (121°C)

Color:
Black (other colors available)

Application Specifications:
SAE-AMS-DTL-23053/5, Class 1 and 2

UL File Number:
E52612 (VW-1 except Clear)

Product Codes

Mfr Part No:hix-1/8 black spooled
EDMO #:HIXR-1/8
Brand:ICO RALLY
Category:Wire, Cable & Accessories
ECCN:EAR99
ECCN:EAR99
MIL SPEC:M23053/5-104-0
MIL SPEC:M23053/5-104-0
MIL SPEC:M23053/5-104-0
MIL SPEC:M23053/5-104-0
MIL SPEC:M23053/5-104-0
SCHEDULE B CODE:3902.30.0000
SCHEDULE B CODE:3902.30.0000
