Aerospace HDMI Cable | DVI-D Plug to DVI-D Plug

Product Description

The GF100-26HDMI is an aerospace grade, high-speed 2.0 HDMI cable designed to support 4K p60/59, 12Gbps images up to 15 ft, as well as, 4K p30/24, 6Gbps and 1080p 60Hz up to 50 ft. This 26 AWG HDMI cable is backward compatible to all current features pertinent to the HDMI specifications.

This HDMI cable (EDMO# GFAHDMI305) is 60 inches and a DVI-D Plug to DVI-D Plug cable.

Specifications

• Weight:
  76 lbs/1000ft (113.1 kg/1000m)
• Outer Diameter:
  0.296 in (7.52mm)
• Operating Temperature:
  -55° to 150°C
• Minimum Bend Radius:
  1.5 in (38.1mm)
• Impedance:
  100Ω
• Capacitance:
  14.5 pF/ft (47.57 pf/m)
• Velocity of Propagation:
  75% DC
• Resistance:
  43.9 Ω/1000ft (144.13 Ω/1000m)
• Shield DCR:
  13.3 Ω/1000ft (43.64 Ω/1000m)
• Dielectric Voltage Rating:
  1.5 KV RMS

Product Codes

• Mfr Part No
  GFAHDMI-305-060
• SCHEDULE B CODE
  8544.19.0000
