DWA2000 WAAS GPS Annunciator | 11–32 VDC, Dual LED
Product Description
The DWA2000 is a self-contained WAAS GPS annunciator panel for 14 and 28 volt aircrafts. The unit displays annunciation status from GPS receivers that output discrete signals for remote annunciation purposes.
Features
- Dual LEDs for each annunciator
- Photocell and discrete dimming
Specifications
Weight:
2.0 oz
Dimension:
2.50 x 0.72 x 0.35 in
Case Material:
Aluminum
Operating Temperature:
-55ºC to 70ºC
Survival Temperature:
-55ºC to 85ºC
Humidity:
95%
Altitude:
50,000 ft
Connector:
12 Pin DO-160E
Input Voltage:
11–33 VDC
Current:
0.170 A @ 27.5 VDC
Fuse/Circuit Breaker Rating:
0.5 A
Product Codes
- Mfr Part No:DWA2000-000
- EDMO #:DWA2000
- Brand:DEKLIN TECHNOLOGIES
- Category:GPS Components & Accessories
