DM NI50 DME/ATC L-Band Antenna | 960MHz – 1,220MHz, 4-hole, Type TNC Male Connector, white

Product Description

The DM NI50 reduces maintenance costs due to its low profile, all-metal blade that provides unequalled mechanical strength and reliability. The NI50 antennas are engineered for use on business, commercial, and military aircraft. NI50 DME antennas can be used will all standard L-Band equipment operating on the 960 MHz to 1,220 MHz frequency band. These antennas are interchangeable with with virtually all L-band blade, flush mountable antennas currently in service on commercial and military aircraft.


This DM NI50 DME/ATC antenna (EDMO# DMNI50-9-2) has a glossy white finish, type TNC male connector, and a four-hole mounting pattern.

Specifications

• Weight:
  4 oz
• Height:
  2.2 in
• Frequency Range:
  960 MHz – 1,220 MHz
• VSWR:
  < 1.7:1 (960 MHz – 1,220 MHz) < 1.5:1 (1,000 MHz – 1,100 MHz)
• Gain:
  0 dB, average @ horizon
• Impedance:
  RF: 50Ω DC: short circuit
• Polarization:
  vertical
• Radiation Pattern:
  hemispherical
• Power Handling:
  3kW (peak), 100 watts (average)
• ENVIRONMENTAL:
• Aerodynamic Drag (@ sea level):
  2 oz (mach 0.5) 4.5 oz (mach 0.8)
• Side Load:
  TSO C34c
• ARINC:
  532 E (ATC transponder) 521 D (DME)
• FAA:
  TSO-C74 (ATC transponder) TSO-C66a (DME)

Product Codes

• Mfr Part No
  DM NI50-9-2
• ECCN
  7A994
• PROAPP
  PT1084NE
• SCHEDULE B CODE
  8529.10.4000
• TSO
  C66a,C74,C112
