CI-503 Glide Slope Signal Coupler | 329–335 MHz, 50 Ω, BNC Female Connector

Product Description

The CI 503 glide slope signal coupler (EDMO# CI-503) is a two-through-hole-mount style coupler with BNC ports. This antenna separates a single GS antenna signal into two GS signals and is designed for GS only coupling applications. It is suitable for internal aircraft mounting.

Specifications

• Weight:
  0.20 lb
• Height:
  0.88 in.
• Frequency:
  329–335 MHz
• VSWR:
  1.5:1
• Isolation:
  18 dB
• Insertion Loss:
  3.5 dB
• Impedance:
  50 Ω
• Construction:
  Die Cast Aluminum
• Finish:
  Aluminum
• Connector:
  BNC Female
• Mounting Location:
  Internal
• FAA TSO:
  C34e

Product Codes

• Mfr Part No
  CI 503
• ECCN
  7A994
• NSN
  5985-498-0502
• PROAPP
  PT2316NM
• SCHEDULE B CODE
  8529.10.4000
• TSO
  C34c,C36c,C40a

Documentation

• CI 503 Data Sheet
• CI 503 Product Drawing
