5-Pin XLR Circular Connector | Panel Mount
Product Description
Switchcraft C Series XLR connectors feature a round housing panel mount with a 0.140-inch mounting holes that require #5-40 mounting screws.
This XLR circular connector (EDMO# C5F) is a 3-pin XLR female connector with silver pins and nickel finish. Requires #5 mounting screw (not included).
Features
- 3-pin XLR female connector
- Circular panel mount connector
Specifications
Mount Hole:
0.94 in
Contact Resistance:
50 mΩ, max. per pole
Current Rating:
15A – 3-pole
Insulation Resistance:
1,000 VRMS
Capacitance:
2 pF, between pins
4 pF, between pins and shell
Insertion Force:
5 lb, nominal (7 lb, max.)
Withdrawal Force:
5 lb, nominal (7 lb, max.)
Wire Size:
#12 wire gauge solid
#14 wire gauge stranded (3 contact)
#14 wire gauge solid
#16 wire gauge stranded (4 contact)
#16 wire gauge solid
#18 wire gauge stranded (5 and 6 contact)
#18 wire gauge solid
#20 stranded (7 contact). (Q-G and QGP)
Shell Material:
Die case zinc. satin nickel finish, black velvet
Insertion Insulation:
Molded thermoplastic
Socket Contacts:
Silver-plated, copper alloy
Latchlock:
High-strength die-cast zinc
Latch Release:
Nickel-plated, steel
Latch Detent:
Formed stainless
Insert Screw:
Stainless steel
Flex Relief:
TPR (thermoplastic rubber)
Product Codes
- EDMO #:C5F
- Brand:SWITCHCRAFT
- Category:Electrical Interconnect
