AV-601 Radar Altimeter | 4200–4400 MHz
Product Description
The AV-601 is a radar altimeter antenna specifically designed to meet FAA TSO-C87a specifications. Qualification testing includes meeting the requirements of EUROCAE ED-30, Edition 2, “Minimum Performance Standards for Airborne Low Range Radar Altimeter Equipment,” as modified by Appendix 1 of the TSO.
Features
- 4200–4400 MHz frequency range
- 50 Ω impedance
- Linear polarization
- 45º roll plate radiation pattern
- TNC female connector
- Backed by the RAMI Limited Lifetime Warranty
Specifications
Weight:
0.25 lb. (113g)
Height:
0.14 in
Frequency:
4200–4400 MHz
VSWR:
1.5:1 Max (4275-4325 MHz)
2.3:1 Max (4200-4400 MHz)
Polarization:
Linear
Radiation Pattern:
Roll Plane(E): 45° min
Beam Widths:
Pitch Plane (H): 40° min
Impedance:
50 Ohms
Gain:
9.5 dBi
Isolation H-Plane:
16 in: 80 dB
20 in: 88 dB
30 in: 90 dB
36 in: 95 dB
RF Power Capacity:
5 W (average), 500 W (max)
Side Lobe Level:
-40 dB
Lighting Protection:
DC Grounded
Connector:
TNC Female
Finish:
Skydrol-resistant polyurethane enamel
Mesh Gasket Dimensions:
3.50 x 3.65 x 0.02 in
Compliance:
FAA TSO C87a
Product Codes
- Mfr Part No:AV-601
- EDMO #:AV-601
- Brand:RAMI
- Category:Antennas & Couplers
