Radar Control Test Panel

The ASI-252-2 radar control test panel provides the functions and capabilities necessary to test the Bendix CON-4A/B radar control separated from it operation environment. This test panel receives and decodes ARINC 429 control data and provides power to the CON-4() under test. The test panel thus substitutes its functions for those of the R/T, providing a surrogate operational environment.

The ASI-252-2 receives and decodes ARINC 429 control words 1 and 2 from the CON-4() and displays the decoded data on the front panel seven segment displays and LED's. The ASI-252-2 includes two cables required for proper operation.
