ACP51 Digital Audio Control Panel | Cabin ACP, LED Backlit

Product Description

The ACP51 provides a user control interface for the Digital Audio Control System (DACS). The audio control panel (ACP) is a terminal that sends and receives signals to and from the Audio Management Unit (AMU) and displays system status by way of a series of annunciators integrated into the front panel of the ACP. Model ACP51-101 is designed for cabin crew/mission specialists with transceiver audio controls only. This unit features snap-in legends for the ability to customize radio text.

Snap-In legends sold separately. 16 legends required for each unit (see part# 55-06-xxx or 55-07-xxx). ACP legend kits available ACPLK-XXX. Call for more for info or questions.

This ACP51 Digital Audio Control Panel (EDMO# ACP51-101) has LED Backlighting.

Specifications

• Weight:
  1.01 lb
• Dimensions:
  5.75 x 2.62 x 3 in
• Power:
  27.5 VDC, 2.5A nominal

Product Codes

• Mfr Part No
  ACP51-101
• ECCN
  7A994
• ETSO
  C50c
• PROAPP
  TSO: PT2204NM/PMA: PQ2204NM
• SCHEDULE B CODE
  8525.60.1055
• TSO
  C139

Documentation

• DACS Brochure.pdf
