PIDG Quick Disconnect Receptacle | Series 205, 16 – 14 AWG, Straight Mount
Product Description
The series 205 miniature FASTON terminal connectors feature a low insertion force in applications where there is not enough space for traditional, full-sized straight receptacle. These quick connectors have a tin-plated brass construction for a continuous current rating up to seven amps and 14 amp intermittent current.
This PIDG quick disconnect receptacle (EDMO# 640913-1) has a straight connector, fits 16 – 14 AWG wire, and has a blue insulation color.
Features
- Fits within confined spaces
- Low insertion force provides increased comfort
- Meets UL 310 & CSA C22.2 No. 153 requirements
Specifications
Dimensions:
20.32 x 6.35 mm
Color:
blue
Contact Material:
tin-plate brass
Insulation:
nylon
Mounting Angle:
straight
Mounting Style:
push in
Product Type:
quick disconnect terminal
Product Series:
205 Faston
Stud / Tab Size:
5.21 x 0.51 mm
Termination Style:
crimp
Voltage Rating:
300V
Wire Gauge:
16 – 14 AWG
Product Codes
- Mfr Part No:640913-1
- EDMO #:640913-1
- Brand:TE CONNECTIVITY
- Category:Electrical Interconnect
