TNC RF Connector | 50 Ω, Straight, Crimp, For RG-9/U, RG-9A/U, RG-9B/U, and RG-214/U

5225555-8

TE CONNECTIVITY

CALL FOR PRICING
In Stock
EDMO#5225555-8
MFR#5225555-8

Need help placing an order?
Call 800-235-3300 or Contact Us

Product Description

The Tyco Electronics TNC RF connector family, with 7/16-28 threaded couplings, provides low noise levels and optimum stability, and can withstand the shock and vibration often present in hostile environments.

Available in both 50 Ω and 75 Ω versions, these connectors feature numerous styles including cable plugs and jacks, adapters and printed circuit board connectors. These connectors accept a wide range of coaxial cables and are intermateable with industry standard connectors designed to MIL-C-39012 specifications.

Single crimp connectors provide reduced application time and lower applied costs. This is accomplished by using Tyco Electronics one-crimp operation tooling which simultaneously terminates the inner conductor, outer braid and cable support with one controlled stroke.

This TNC RF connector (EDMO# 5225555-8) has a 50 Ω impedance, straight body, crimp termination, and is designed for use with RG-9/U, RG-9A/U, RG-9B/U, and RG-214/U cables.

Features

  • 50 Ω and 75 Ω commercial versions available

  • Provides excellent performance at frequencies up to 7 GHz

  • Low-cost commercial type available

  • Commercial type is smaller and lighter weight

  • Tarnish resistant nickel finish

  • Choice of dielectric materials

  • Standard and weatherproof versions available

  • Plugs available for high temperature cable

Specifications

Dimensions (L x Dia.):
2.000 x 0.640 in (50.8 x 16.26 mm)

Impedance:
50 Ω

Operating Frequency Range:
11 GHz

Connector Seal & Plug Type:
Gasket

RF Interface:
TNC

RF Connector Style:
Plug

Body Orientation:
Straight

Termination Type:
Crimp

Compatible RF Cables:
RG-9/U, RG-9A/U, RG-9B/U, and RG-214/U

Connector System:
Cable-to-Cable

Sealable:
Yes

Contact Crimp Type:
Dual Crimp

Connector Coupling Mechanism:
Threaded

Connector Mounting Type:
Free-hanging (in-line)

Body Material:
Nickel Plated Brass

Contact Material:
Gold Plated Brass

Dielectric Material:
Polytetrafluoroethylene (PTFE)

Product Codes

  • Mfr Part No:5225555-8
  • EDMO #:5225555-8
  • Brand:TE CONNECTIVITY
  • Category:Electrical Interconnect
  • CSA:LR 7189
  • CSA:LR 7189
  • ECCN:EAR99
  • ECCN:EAR99
  • ROHS:YES
  • ROHS:YES
  • SCHEDULE B CODE:8205.59.5560
  • SCHEDULE B CODE:8205.59.5560
  • UL:E81956
  • UL:E81956
