MIL-DTL-26482 Series I Circular Connector | 3-Contact, Straight, Solder Pin


COMM INNOVATIONS

Call For Pricing
Available to order
EDMO # 3116P123P
MFR Part # MS3116P12-3P
Need help placing an order? Call 800-235-3300 or Contact us

Product Description

MIL-DTL-26482 Series I are commercial grade circular connectors provide the performance and versatility when needed in applications demanding high reliability.

This Mil-Spec 3-pin circular connector (EDMO# 3116P123P) is a solder type, straight connector.

Features

  • Aluminum shell components with 5 key/keyway conductive plating
  • RoHS compliant harsh environment conductive plating
  • Dependable 5-key/keyway polarization with bayonet lock coupling assures positive mating
  • Insert and main joint gasket are molded from resilient neoprene provides moisture sealing
  • Gold-plated copper alloy pins and sockets

Specifications

  • Connector Type:
    Plug, Male Pins
  • Shell Size:
    12-3
  • Mounting Type:
    In-Line
  • Fastening Type:
    Bayonet Lock
  • Number of Positions:
    3
  • Termination:
    Solder cup
  • Shell Material:
    Aluminum
  • Finish:
    Olive drab cadmium plated
  • Orientation:
    Normal
  • Compliance:
    RoHS

Related Products

Product Codes

  • Mfr Part No
    MS3116P12-3P
  • SCHEDULE B CODE
    8525.60.1025
