Dual Ammeter-Voltmeter | 2-1/4 in, 30A, 30V, 1C1 Shunt
Product Description
UMA dual ammeter & voltmeters are rugged and reliable instruments for measuring the current within the aircraft's electrical system. For easy of installation, UMA Amp meters use an external shunt to make current measurements.
This 2-1/4 inch dual volt/amp meter (EDMO# 15-200-030) has a black & white dial markings with post terminal, measures up to 30 amps and 30 volts, has a moving coil movement, and 1C1 shunt.
Features
- 2-1/4 inch ammeters are available in either air-core movement or moving coil types
- 1-1/4 inch ammeters use air-core movement
- Optional Opti-Alert system available for 2-1/4 inch instruments
- Color marking and internal lighting are also available
Specifications
Mounting Hole:
2-1/4 in
Shunt:
50 mA
Amperage Range:
30A
Voltage Range:
30V
Product Codes
- Mfr Part No:15-200-030
- EDMO #:15-200-030
- Brand:UMA INSTRUMENTS
- Category:Clocks & Instruments
